Communication Ports
SYNC (Video Sync In)
The 4-Pin 00B Sync Connector accepts timecode, genlock, and General Purpose Input (GPI) signals.
4-Pin 00B Sync Connector |
|||
pin |
signal |
Description |
Direction |
1 |
GROUND |
Common ground |
N/A |
2 |
SS/GPI |
Shutter sync/general purpose input trigger |
In |
3 |
TIMECODE |
SMPTE unbalanced timecode input |
In |
4 |
GENLOCK |
Tri-level sync input |
In |
NOTE: Mating connector is FGG.00.304.CLAD.
SYNC Trigger Button Circuit
The SYNC connector has a 3.3 V Schmitt trigger (5 V tolerant). The trigger is not a switch closure circuit, so it requires that the trigger source supplies current. Both edges of the input signal may be used as a trigger.
For example, this is the behavior of the circuit when the GPI trigger is used for record start/stop:
- Start Record: On ground to 3.3 V transition
- During Record: Hold at 3.3 V
- Stop Record: On 3.3 V to ground transition
- During Stop: Hold at ground
NOTE: In the diagram above, values are approximate. Use standard values.
Compatible Cables
- 790-0154, 790-0643: 3BNC-to-00 Sync Cable
- 790-0187, 790-0648: 4-Pin 00B-to-Flying Lead
- 790-0415: RED Start/Stop Cable (14-Pin 1B to SYNC, CTRL, BNC)
- 790-0428: RED Start/Stop Cable (14-Pin to 00B SYNC)
CTRL (RS232 Control)
The 4-Pin 00B CTRL Connector supports RS232 remote control for 3D camera communication and third-party metadata ingest applications. For more information, go to BRAIN GPIO.
The General Purpose Out (GPO) tally presents 3.3 V at a maximum of 0.04 A between pins 1 and 3. When used as a record tally, the rising edge of the pulse indicates start of record, falling edge represents end of record.
For more information about controlling the camera via RS232, download the R.C.P.™ SDK.
4-Pin 00B CTRL Connector |
|||
pin |
signal |
description |
Direction |
1 |
GROUND |
Common ground |
N/A |
2 |
232 RX |
RS232 RX |
In |
3 |
SS/GPO |
Shutter sync/general purpose output |
Out |
4 |
232 TX |
RS232 TX |
Out |
NOTE: Mating connector is FGG.00.304.CLAD.
Compatible Cables
- 790-0154, 790-0643: 3BNC-to-00 Sync Cable
- 790-0187, 790-0648: 4-Pin 00B-to-Flying Lead
- 790-0415: RED Start/Stop Cable (14-Pin 1B to SYNC, CTRL, BNC)
GIG-E (Ethernet)
The GIG-E 9-pin 0B connector provides a 1000BASE-T (IEEE 802.3ab) gigabit Ethernet connection for remote camera setup, master/slave camera communication, and external metadata ingest. Since the GIG-E connector does not support slower speeds (10BASE-T and 100BASE-T), ensure that any device you connect to supports 1000BASE-T.
9-Pin 0B GIG-E connector |
|||
pin |
signal |
description |
direction |
1 |
BI_DC+ |
Data pair C+ |
N/A |
2 |
BI_DC- |
Data pair C- |
N/A |
3 |
BI_DD+ |
Data pair D+ |
N/A |
4 |
BI_DD- |
Data pair D- |
N/A |
5 |
BI_DA- |
Data pair A- |
N/A |
6 |
BI_DA+ |
Data pair A+ |
N/A |
7 |
BI_DB+ |
Data pair B+ |
N/A |
8 |
BI_DB- |
Data pair B- |
N/A |
9 |
N/A |
Do not connect |
N/A |
NOTE: Mating connector is FGG.0B.309.CLAD.
Compatible Cables
- 790-0159: RED GIG-E Straight-to-CAT5E Ethernet Cable (9')
-
790-0557, 790-0655: RED GIG-E Right-to-CAT5E Ethernet Cable (9')
- 790-0163: Master/Slave Gig-E Cable (4')
