GIG-E Port
The GIG-E ODU 9-Pin 0L connector provides a 1000BASE-T (IEEE 802.3ab) Gigabit Ethernet connection remote camera control, Precision Time Protocol (SMPTE 2059-1) sensor and frame synchronization, and accessing the 1080p IP video stream.
The GIG-E port does not support slower speeds (10BASE-T and 100BASE-T). Make sure that the devices you connect to the GIG-E port support 1000BASE-T.
Figure: Front Face of the GIG-E Connector (looking at the back of the camera).
ODU 9-Pin OL Connector
|
pin |
signal |
description |
|
1 |
BI_DC+ |
Data pair C+ |
|
2 |
BI_DC- |
Data pair C- |
|
3 |
BI_DD+ |
Data pair D+ |
|
4 |
BI_DD- |
Data pair D- |
|
5 |
BI_DA+ |
Data pair A+ |
|
6 |
BI_DA- |
Data pair A- |
|
7 |
BI_DB+ |
Data pair B+ |
|
8 |
BI_DB- |
Data pair B- |
|
9 |
NA |
Do not connect |
NOTE: Mating connector is LEMO FGG.0B.309.CLAD.
Compatible Cable
790-0655: RED GIG-E Right-to-CAT5E Ethernet Cable (9')
