Quick Reference
Congratulations new RED Cine-Broadcast owner. This quick reference topic helps you get familiar with this guide and the RED Cine-Broadcast Components. It includes links to topics about configuring the Cine-Broadcast components to fit your recording requirements, and for learning the basic operation of the camera.
Preparing the Camera Hardware
Refer to the appropriate Operation Guide for your camera model at https://www.red.com/downloads.
Preparing the RED Cine-Broadcast System
Configure the Cine-Broadcast settings to prepare for recording by configuring the Cine-Broadcast system EVF (refer to How-To).
Connecting the Returns on the Base Station
Connect RET SEL IN with one of the RET SEL OUTs by using the supplied BNC cable. This is required even when no return video is sent to the module.
Half Rack:
Full Rack:
