Base Station (Full) Mounts

The RED Cine-Broadcast Base Station (Full) includes rack mounting brackets.

Use the included rack mounting brackets when you are installing the RED Cine-Broadcast Base Station Full in a rack.

Use three M4-8 screws and one M4-5 short screw to attach each of the two brackets to the base station as shown in the diagram:
