Powering the Module

WARNING: Never connect power to the camera’s DC-IN port when the module is attached. This will damage the 10G link in the module.

You must only power a Cine-Broadcast Module-equipped camera by using the module's OPT base station cable connection or the 4-Pin XLR DC-IN connection.

When the base station is powered by DC, you must use the module's 4-Pin XLR DC-IN connection.

#	Item	Description
1	OPT	LEMO, SMPTE 304M, Base Station connection
2	DC IN	4-Pin male XLR, 14 V DC



If you connect the RED Cine-Broadcast module to the camera with the RED Connect CFexpress bridge and the OPT base station cable is NOT connected, and the power is connected to the camera’s DC-IN port, you will permanently damage the 10G link in the module.
