Long-Range Transmission

Broadcast setups can vary significantly depending on rigging configurations and cable manufacturers. These variables influence signal integrity, transmission length, and overall reliability.

For typical transmission, SMPTE 311M/304M hybrid fiber cables are recommended. These cables are engineered for high-bandwidth, low-latency video and audio signals, making them ideal for both studio and field environments.

For extremely long runs, we recommend using breakout cables (see diagram below) for signal transmission, and applying power to the Base Station and Module locally and independently.

Long-Range Signal Extension Solution
